Dimensions:
2.2 x 1.35 x 1mm
Maximum Continuous Drain Current:
310 mA
Transistor Material:
Si
Width:
1.35mm
Transistor Configuration:
Single
Maximum Drain Source Voltage:
60 V
Maximum Gate Threshold Voltage:
2.1V
Package Type:
SOT-323
Number of Elements per Chip:
1
Minimum Gate Threshold Voltage:
1.1V
Maximum Operating Temperature:
+150 °C
Typical Gate Charge @ Vgs:
0.5 nC
Channel Type:
N
Typical Input Capacitance @ Vds:
33 pF@ 10 V
Length:
2.2mm
Pin Count:
3
Typical Turn-Off Delay Time:
12 ns
Mounting Type:
Surface Mount
Channel Mode:
Enhancement
Maximum Power Dissipation:
0.33 W
Maximum Gate Source Voltage:
±20 V
Height:
1mm
Typical Turn-On Delay Time:
5 ns
Minimum Operating Temperature:
-55 °C
Maximum Drain Source Resistance:
2 Ω
