Broadcom HSMS-2802-BLKG Dual SMT Schottky Diode, Series, 70V 15mA, 3-Pin SOT-23

HSMS-2802-BLKG Broadcom Dual SMT Schottky Diode, Series, 70V 15mA, 3-Pin SOT-23
HSMS-2802-BLKG
HSMS-2802-BLKG
ET13946059
ET13946059
Unclassified
Broadcom

Product Information

Dimensions:
3.13 x 1.5 x 1.2mm
Mounting Type:
Surface Mount
Diode Technology:
Schottky
Maximum Continuous Forward Current:
15mA
Maximum Operating Temperature:
+150 °C
Maximum Forward Voltage Drop:
410mV
Height:
1.2mm
Peak Reverse Current:
200nA
Width:
1.5mm
Length:
3.13mm
Package Type:
SOT-23
Number of Elements per Chip:
2
Diode Type:
Schottky
Diode Configuration:
Series
Pin Count:
3
Peak Reverse Repetitive Voltage:
70V
RoHs Compliant
Checking for live stock

This is Dual SMT Schottky Diode Series 70V 15mA 3-Pin SOT-23 manufactured by Broadcom. The manufacturer part number is HSMS-2802-BLKG. The given dimensions of the product include 3.13 x 1.5 x 1.2mm. The product is available in surface mount configuration. The product utilizes schottky diode technology. Furthermore, its maximum continuous forward current constitutes 15ma. It has a maximum operating temperature of +150 °c. It features 410mv of maximum forward voltage drop. In addition, the height is 1.2mm. It has a typical 200na peak reverse current . Furthermore, the product is 1.5mm wide. Its accurate length is 3.13mm. The package is a sort of sot-23. It consists of 2 elements per chip. It is designed with a schottky diode. The diode features a series configuration. It contains 3 pins. While having the peak reverse repetitive 70v.

pdf icon
HSMS-280x Surface Mount RF Schottky Barrier Diodes(Technical Reference)
pdf icon
ESD Control Selection Guide V1(Technical Reference)
