Molex 19070 Series Insulated Tin Plated Crimp Terminal, M5 (#10) Stud Size, 1mm² to 2.5mm², 16AWG to 14AWG, Blue

19070-0092 Molex 19070 Series Insulated Tin Plated Crimp Terminal, M5 (#10) Stud Size, 1mm² to 2.5mm², 16AWG to 14AWG, Blue
Molex

Product Information

Minimum Wire Size mm²:
1mm²
Maximum Wire Size mm²:
2.5mm²
Minimum Wire Size AWG:
16AWG
Series:
19070
Colour:
Blue
Shrouded:
Shrouded
Thickness:
0.79mm
Stud Size:
M5 (#10)
Outer Ring Diameter:
8.18mm
Inner Ring Diameter:
5.03mm
Insulation Material:
PVC
Contact Plating:
Tin
Overall Length:
22.1mm
Insulation:
Insulated
Maximum Wire Size AWG:
14AWG
Contact Material:
Copper
Series Number:
0092
RoHs Compliant
Checking for live stock

This is 19070 Series Insulated Tin Plated Crimp Terminal M5 (#10) Stud Size 1mm² to 2.5mm² 16AWG to 14AWG Blue manufactured by Molex. The manufacturer part number is 19070-0092. On the other hand, the wire has 1mm² of minimum size. The wire has a maximum size of 2.5mm². While the minimum wire size AWG includes 16awg. The product 19070, is a highly preferred choice for users. It has a decent blue colour. It is shrouded . It is 0.79mm thick. It has a standard m5 (#10) size stud . In addition, its outlet ring diameter is about 8.18mm . Moreover, the inner ring is about 5.03mm in diameter . It has a robust pvc insulation material. The high-quality tin is used as contact plating material. It has an overall length of 22.1mm. Insulation Option: insulated. Its maximum wires size includes 14awg. The product is made from sturdy copper materials. It carries [Serial Number] serial number.

pdf icon
Datasheet(Technical Reference)
pdf icon
Line Drawing(Technical Reference)
