Maximum Temperature:
+40°C
Cable Length:
1800mm
Minimum Temperature:
0°C
Regulator Type:
Switched Mode Power Supply
Application:
Low-Power Computers, Networking, Peripherals & Terminals, Portable Equipment
Protection Features:
Over Current Protection, Over Voltage Protection, Short Circuit Protection
Output Current Range:
3A
Maximum Input Current:
250 mArms @ 240 V ac, 500 mArms @ 120 V ac
Holdup Time:
10ms
Standards Met:
CE, Class B EMI, CULus, EISA Compliant, Level V Efficiency Compliant
Input Connector:
IEC320-C8
Input Frequency Range:
47 → 63Hz
Energy Efficiency Level:
V
Overall Length:
81.2mm
Overall Depth:
29.8mm
Number of Outputs:
1
Operating Temperature Range:
0 → +40 °C
Rated Output Power:
15W
Ripple And Noise:
70mV Pk-Pk
Output Voltage Rating:
5 V dc
Special Features:
No Load Power Saving <0.3W
Power Signal Conversion Type:
AC-DC
Overall Dimensions:
81.2 x 50 x 29.8mm
Weight:
140g
Mounting Type:
Desktop
Line Regulation Range:
±5%
Series:
PSAA15W
Overall Width:
50mm
Output Connection Type:
2.1 x 5.5 x 9.5 mm Centre Positive
Load Regulation Range:
±5%
Input Voltage Range:
90 → 264 V ac
