Maximum Temperature:
+40°C
Minimum Temperature:
0°C
Regulator Type:
Switched Mode Power Supply
Application:
Gaming Machines, Networking, Peripherals, Portable Equipment
Protection Features:
Over Current Protection, Over Voltage Protection, Short Circuit Protection
Output Current Range:
2.5A
Maximum Input Current:
0.7 A @ 240 V ac, 1.5 A @ 120 V ac
Standards Met:
CE, Class B EMI, CULus, EISA Compliant, Level V Efficiency Compliant
Input Connector:
IEC320-C6
Input Frequency Range:
47 → 63Hz
Energy Efficiency Level:
V
Overall Length:
130mm
Overall Depth:
32mm
Number of Outputs:
1
Operating Temperature Range:
0 → +40 °C
Rated Output Power:
60W
Ripple And Noise:
350mV Pk-Pk
Output Voltage Rating:
24 V
Special Features:
Low Profile Design, No Load Power Consumption
Power Signal Conversion Type:
AC-DC
Overall Dimensions:
130 x 60 x 32mm
Mounting Type:
Desktop
Weight:
305g
Line Regulation Range:
±5%
Series:
PSAC60M
Input Voltage Range:
100 → 240 V ac
Cable Length:
1200mm
Output Connection Type:
2.1 x 5.5 x 9.5 mm Centre Positive
Load Regulation Range:
±5%
Overall Width:
60mm
