Vishay VS-63CTQ100-N3 Dual Schottky Diode, Common Cathode, 100V 30A, 3-Pin TO-220AB

VS-63CTQ100-N3 Vishay Dual Schottky Diode, Common Cathode, 100V 30A, 3-Pin TO-220AB
VS-63CTQ100-N3
VS-63CTQ100-N3
ET13883868
ET13883868
Vishay

Product Information

Dimensions:
9.02 x 10.66 x 4.82mm
Mounting Type:
Through Hole
Diode Technology:
Schottky
Maximum Continuous Forward Current:
30A
Maximum Operating Temperature:
+175 °C
Peak Non-Repetitive Forward Surge Current:
1.5kA
Height:
9.02mm
Peak Reverse Current:
300µA
Width:
4.82mm
Length:
10.66mm
Package Type:
TO-220AB
Number of Elements per Chip:
2
Minimum Operating Temperature:
-65 °C
Diode Type:
Schottky
Diode Configuration:
Common Cathode
Pin Count:
3
Peak Reverse Repetitive Voltage:
100V
RoHs Compliant
Checking for live stock

This is Dual Schottky Diode Common Cathode 100V 30A 3-Pin TO-220AB manufactured by Vishay. The manufacturer part number is VS-63CTQ100-N3. The given dimensions of the product include 9.02 x 10.66 x 4.82mm. The product is available in through hole configuration. The product utilizes schottky diode technology. Furthermore, its maximum continuous forward current constitutes 30a. It has a maximum operating temperature of +175 °c. Moreover, a bespoke product has 1.5ka peak non-repetitive forward surge current. In addition, the height is 9.02mm. It has a typical 300µa peak reverse current . Furthermore, the product is 4.82mm wide. Its accurate length is 10.66mm. The package is a sort of to-220ab. It consists of 2 elements per chip. Whereas, the minimum operating temperature of the product is -65 °c. It is designed with a schottky diode. The diode features a common cathode configuration. It contains 3 pins. While having the peak reverse repetitive 100v.

pdf icon
ESD Control Selection Guide V1(Technical Reference)
pdf icon
Diode Schottky 100V 30A(Technical Reference)

Reviews

  • Be the first to review.

FAQs

Yes. You can also search VS-63CTQ100-N3 on website for other similar products.
We accept all major payment methods for all products including ET13883868. Please check your shopping cart at the time of order.
You can order Vishay brand products with VS-63CTQ100-N3 directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Unclassified category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Vishay VS-63CTQ100-N3 Dual Schottky Diode, Common Cathode, 100V 30A, 3-Pin TO-220AB. You can also check on our website or by contacting our customer support team for further order details on Vishay VS-63CTQ100-N3 Dual Schottky Diode, Common Cathode, 100V 30A, 3-Pin TO-220AB.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET13883868 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Vishay" products on our website by using Enrgtech's Unique Manufacturing Part Number ET13883868.
Yes. We ship VS-63CTQ100-N3 Internationally to many countries around the world.
