Maximum Temperature:
+70°C
AC or DC Output Voltage:
Dc
Minimum Temperature:
-20°C
AC or DC Input Voltage:
Ac
Width:
40mm
MTBF:
944.6kh
Maximum Output Voltage:
12V dc
Electrical Phase:
1
Protection Features:
Brown Out, Over Voltage Protection, Overload Protection, Short Circuit Protection
Type:
Switch Mode
Holdup Time:
>32 ms @ 230 V ac
Standards Met:
CE, CULus, E 361935, EN 55022:2006+A1:2007 Class B, EN 55024:1998+A1:2001+A2:2003, EN 61000-3-2:2006 Class A, EN 61000-3-3:2008, EN 61204-3:2000, NEC Class 2, RoHS, TUV, TUV EN 60950-1:2006+A11, UL 1310, UL 508, Ulus
Maximum Input Current:
1.3 A @ 115 V ac
Input Frequency Range:
47 → 63Hz
Efficiency:
86%
Input Voltage:
88 → 264V ac
Number of Outputs:
1
Output Voltage Adjustment Range:
10.8 → 13.2V
Line Regulation:
±1%
Ripple And Noise:
100mV Pk-Pk
Range:
PSC
Minimum Output Voltage:
12V dc
Special Features:
High Efficiency, High Reliability, Long Life, True DC OK Signal Output, Universal AC Input, 3-Year Product Warranty
Input Electrical Phase:
Single Phase
Power Signal Conversion Type:
AC-DC
Mounting Type:
DIN Rail
Output Current:
0 → 5A
Application:
Industrial
Series:
PSC-60
Depth:
99mm
Height:
90mm
Output Voltage:
12 V dc
Power Rating:
60W
Maximum Input Voltage:
264V ac
Minimum Input Voltage:
88V ac
