Maximum Temperature:
+70°C
AC or DC Output Voltage:
Dc
Minimum Temperature:
-25°C
AC or DC Input Voltage:
Ac
Width:
55mm
MTBF:
>500h
Maximum Output Voltage:
24V dc
Electrical Phase:
2
Protection Features:
Over Temperature Protection, Over Voltage Protection, Overload Protection, Short Circuit Protection
Type:
Switch Mode
Holdup Time:
20ms
Standards Met:
EN 50178, EN 60950-1, EN 61000-3-2, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-6-2, EN 61000-6-4, IEC/EN 60950, PELV EN 60204-1, UL 508
Maximum Input Current:
1.5A
Input Frequency Range:
47 → 63Hz
Efficiency:
>91%
Input Voltage:
187 → 264V ac
Number of Outputs:
1
Output Voltage Adjustment Range:
22 → 27V
Line Regulation:
±0.5%
Ripple And Noise:
100mV Pk-Pk
Range:
PSB
Minimum Output Voltage:
24V dc
Allowed Circuit Configurations:
Parallel
Special Features:
Built-In DC OK Relay Contact, Cooling by Free Air Convection, Multiple Overload & Short Circuit Modes
Input Electrical Phase:
Two Phase
Power Signal Conversion Type:
AC-DC
Mounting Type:
DIN Rail
Output Current:
7.5 A
Application:
Industrial
Series:
PSB-180
Depth:
105mm
Height:
110mm
Weight:
0.6kg
Output Voltage:
24 V dc
Power Rating:
180W
Maximum Input Voltage:
264V ac
Minimum Input Voltage:
187V ac
