Category:
Power MOSFET
Dimensions:
6.73 x 6.22 x 2.39mm
Maximum Continuous Drain Current:
28 A
Transistor Material:
Si
Width:
6.22mm
Transistor Configuration:
Single
Maximum Drain Source Voltage:
55 V
Maximum Gate Threshold Voltage:
2V
Maximum Drain Source Resistance:
40 mΩ
Package Type:
DPAK (TO-252)
Number of Elements per Chip:
1
Minimum Gate Threshold Voltage:
1V
Maximum Operating Temperature:
+175 °C
Typical Gate Charge @ Vgs:
25 nC @ 5 V
Channel Type:
N
Typical Input Capacitance @ Vds:
880 pF@ 25 V
Length:
6.73mm
Pin Count:
3
Typical Turn-Off Delay Time:
21 ns
Mounting Type:
Surface Mount
Channel Mode:
Enhancement
Maximum Power Dissipation:
68 W
Series:
HEXFET
Maximum Gate Source Voltage:
-16 V, +16 V
Height:
2.39mm
Typical Turn-On Delay Time:
8.9 ns
Minimum Operating Temperature:
-55 °C
