Maximum Temperature:
60°C
AC or DC Output Voltage:
Dc
Minimum Temperature:
-10°C
AC or DC Input Voltage:
Ac
Width:
65.5mm
MTBF:
136.8Kh
Maximum Output Voltage:
24V dc
Electrical Phase:
1
Protection Features:
Over Temperature Protection, Over Voltage Protection, Overload Protection, Short Circuit Protection
Type:
Switch Mode
Holdup Time:
32 (115 V ac) ms, 36 (230 V ac) ms
Standards Met:
-3, Compliance to EN 55011, Compliance to EN 61000-3-2, Compliance to EN 61000-4-2, EN 50082-2, EN 55022 (CISPR22) Class B, EN 55024, EN 60950-1 Approved, EN 61000-6-2, ENV 50204, UL 508, UL 60950-1, 3 ,4, 5, 6, 8, 11
Maximum Input Current:
2.6A
Input Frequency Range:
47 → 63Hz
Efficiency:
84%
Input Voltage:
85 → 264V ac
Number of Outputs:
1
Output Voltage Adjustment Range:
24 → 28V
Line Regulation:
±0.5%
Ripple And Noise:
80mV Pk-Pk
Range:
PS
Minimum Output Voltage:
24V dc
Special Features:
Cooling by Free Air Convection, LED Indicator
Input Electrical Phase:
Single Phase
Power Signal Conversion Type:
AC/DC-DC
Mounting Type:
DIN Rail
Output Current:
5 A
Application:
Industrial
Series:
PS-120
Depth:
100mm
Height:
125mm
Weight:
0.79kg
Output Voltage:
24 V dc
Power Rating:
120W
Maximum Input Voltage:
264V ac
Minimum Input Voltage:
88V ac
