Maximum Temperature:
70°C
AC or DC Output Voltage:
Dc
Minimum Temperature:
-20°C
AC or DC Input Voltage:
Ac
Width:
227mm
MTBF:
180.9Kh
Maximum Output Voltage:
48V dc
Electrical Phase:
1
Protection Features:
Over Temperature Protection, Over Voltage Protection, Overload Protection, Short Circuit Protection
Type:
Switch Mode
Holdup Time:
16ms
Standards Met:
-3 (For DRP-480), Compliance to EN 55022 (CISPR22) Class B, Compliance to EN 61000-3-2, Compliance to EN 61000-4-2, EN 60950 Approved, EN 61000-6-2 (EN 50082-2) Heavy Industry Level Criteria A, ENV 50204, UL 508, UL 60950-1, 3 ,4, 5, 6, 8, 11
Maximum Input Current:
4A
Input Frequency Range:
47 → 63Hz
Efficiency:
89%
Input Voltage:
180 → 264V ac
Number of Outputs:
1
Output Voltage Adjustment Range:
48 → 53V
Line Regulation:
±0.5%
Ripple And Noise:
120mV Pk-Pk
Range:
PSP
Minimum Output Voltage:
48V dc
Special Features:
Built-In Constant Current Limiting Circuit, Cooling by Free Air Convection, 100% Full Load Burn-In Test
Input Electrical Phase:
Single Phase
Power Signal Conversion Type:
AC/DC-DC
Mounting Type:
DIN Rail
Output Current:
10 A
Application:
Industrial
Series:
PSP-480
Depth:
100mm
Height:
125.2mm
Weight:
2.4kg
Output Voltage:
48 V dc
Power Rating:
480W
Maximum Input Voltage:
264V ac
Minimum Input Voltage:
180V ac
