Vishay VTVS36ASMF-M3-08, Uni-Directional TVS Diode, 400W, 2-Pin DO-219AB

VTVS36ASMF-M3-08 Vishay , Uni-Directional TVS Diode, 400W, 2-Pin DO-219AB
Vishay

Product Information

Dimensions:
2.9 x 1.9 x 0.98mm
Direction Type:
Uni-Directional
Capacitance:
342pF
Maximum Clamping Voltage:
61V
Diode Configuration:
Single
Automotive Standard:
AEC-Q101
Test Current:
1mA
Maximum Peak Pulse Current:
6.24A
Minimum Breakdown Voltage:
40.9V
Maximum Reverse Leakage Current:
50nA
Package Type:
DO-219AB
Number of Elements per Chip:
1
Maximum Operating Temperature:
+175 °C
ESD Protection:
Yes
Length:
2.9mm
Pin Count:
2
Peak Pulse Power Dissipation:
400W
Maximum Reverse Stand-off Voltage:
36V
Mounting Type:
Surface Mount
Width:
1.9mm
Height:
0.98mm
Minimum Operating Temperature:
-55 °C
RoHs Compliant
Checking for live stock

This is Uni-Directional TVS Diode 400W 2-Pin DO-219AB manufactured by Vishay. The manufacturer part number is VTVS36ASMF-M3-08. The given dimensions of the product include 2.9 x 1.9 x 0.98mm. While is configured as uni-directional. It provides a 342pf of capacitance value. It is supplied with 61v of maximum clamping voltage. The diode features a single configuration. The product complies with automotive standard - aec-q101. In addition, it has 1ma test current. It also has 6.24a maximum peak pulse current. It harbours a 40.9v of minimum breakdown voltage. The product has a maximum 50na of reverse leakage current. The package is a sort of do-219ab. It consists of 1 elements per chip. It has a maximum operating temperature of +175 °c. ESD Protected - yes. Its accurate length is 2.9mm. It contains 2 pins. It has 400w of peak pulse power dissipation. While the maximised reverse stand-off voltage includes 36v. The product is available in surface mount configuration. Furthermore, the product is 1.9mm wide. In addition, the height is 0.98mm. Whereas, the minimum operating temperature of the product is -55 °c.
