Diodes Inc SMAJ75A-13-F, Uni-Directional TVS Diode, 400W, 2-Pin DO-214AC

SMAJ75A-13-F Diodes Inc , Uni-Directional TVS Diode, 400W, 2-Pin DO-214AC
SMAJ75A-13-F
DiodesZetex

Product Information

Maximum Peak Pulse Current:
3.3A
Maximum Reverse Stand-off Voltage:
75V
Dimensions:
4.6 x 2.92 x 2.1mm
Mounting Type:
Surface Mount
Direction Type:
Uni-Directional
Surge Current Rating:
40A
Maximum Operating Temperature:
+150 °C
Maximum Reverse Leakage Current:
5µA
Minimum Breakdown Voltage:
83.3V
Peak Pulse Power Dissipation:
400W
Height:
2.1mm
Width:
2.92mm
Length:
4.6mm
Package Type:
DO-214AC (SMA)
Number of Elements per Chip:
1
Minimum Operating Temperature:
-55 °C
Maximum Clamping Voltage:
121V
Diode Configuration:
Single
Pin Count:
2
Test Current:
1mA
RoHs Compliant
Checking for live stock

This is Diodes Inc Uni-Directional TVS Diode 400W 2-Pin DO-214AC manufactured by DiodesZetex. The manufacturer part number is SMAJ75A-13-F. It also has 3.3a maximum peak pulse current. While the maximised reverse stand-off voltage includes 75v. The given dimensions of the product include 4.6 x 2.92 x 2.1mm. The product is available in surface mount configuration. While is configured as uni-directional. It has about 40a surge current rating . It has a maximum operating temperature of +150 °c. The product has a maximum 5µa of reverse leakage current. It harbours a 83.3v of minimum breakdown voltage. It has 400w of peak pulse power dissipation. In addition, the height is 2.1mm. Furthermore, the product is 2.92mm wide. Its accurate length is 4.6mm. The package is a sort of do-214ac (sma). It consists of 1 elements per chip. Whereas, the minimum operating temperature of the product is -55 °c. It is supplied with 121v of maximum clamping voltage. The diode features a single configuration. It contains 2 pins. In addition, it has 1ma test current.

pdf icon
ESD Control Selection Guide V1(Technical Reference)
pdf icon
SMAJ5.0(C)A - SMAJ200(C)A, 400W Surface Mount Transient Voltage Suppressor(Technical Reference)
