Maximum Low Level Output Current:
.02mA
Dimensions:
6.6 x 4.5 x 0.95mm
Mounting Type:
Surface Mount
Maximum Propagation Delay Time @ Maximum CL:
20ns
Minimum Operating Supply Voltage:
1.65 V
Logic Function:
Voltage Level Translator
Logic Family:
LVCMOS, LVTTL
Maximum High Level Output Current:
-0.02mA
Package Type:
TSSOP
Output Type:
3 State
Minimum Operating Temperature:
-40 °C
Maximum Operating Supply Voltage:
5.5 V
Translation:
BiCMOS
Maximum Operating Temperature:
+85 °C
Pin Count:
20
Propagation Delay Test Condition:
50pF
Number of Elements per Chip:
8
Translator Type:
Voltage Level
HTSUS:
8542.39.0001
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-40°C ~ 85°C (TA)
Package / Case:
20-TSSOP (0.173", 4.40mm Width)
Input Signal:
-
REACH Status:
REACH Unaffected
Output Type:
Tri-State, Non-Inverted
Output Signal:
-
Data Rate:
35Mbps
Package:
Tube
Channel Type:
Bidirectional
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Voltage - VCCB:
1.65 V ~ 5.5 V
Voltage - VCCA:
1.2 V ~ 5.5 V
standardLeadTime:
25 Weeks
Number of Circuits:
1
Channels per Circuit:
8
Features:
Auto-Direction Sensing, Power-Supply Decoupling
Mounting Type:
Surface Mount
Series:
-
Supplier Device Package:
20-TSSOP
Base Product Number:
MAX3002
ECCN:
EAR99
