Maximum Voltage:
240V ac/dc
Width:
90mm
Supply Voltage:
24 → 240V ac/dc
Maximum Current:
8A
Time Range:
0.05 → 1 s, 0.3 → 3 s, 1 → 10 s, 10 → 100 s, 3 → 30 h, 3 → 30 min, 3 → 30 s, 30 → 300 h, 30 → 300 min, 30 → 300s
Mode of Operation:
Interval Delay, Interval Delay with Control Signal Off, Interval Delay with Control Signal Off and with Pause/Summation Control, Interval Delay with Pause/Summation Control Signal, Interval Delay with Retrigger/Restart Control Signal, OFF Delay with Control Signal, OFF Delay with Control Signal and with Pause/Summation, ON Delay and OFF Delay with Control Signal, Power ON Delay, Power ON Delay with Pause/Summation Control Signal, Power ON Delay with Retrigger/Restart Control, Symmetrical, Symmetrical with Pause/Summation Control Signal, Symmetrical with Retrigger/Restart Control Signal
Number of Timer Functions:
Multi Function
Maximum Operating Temperature:
+60°C
Terminal Type:
Screw
Time Delay:
<100ms
Time Increment:
Hours, Minutes, Seconds
Power Supply:
External
Switch Configuration:
SPCO
Contact Configuration:
SPDT
Length:
22.9mm
Minimum Voltage:
24V ac/dc
Better World Verification:
Green Premium
Better World Product:
Yes
Mounting Type:
DIN Rail
Series:
Harmony Time
Depth:
79.5mm
Minimum Current:
10mA
Minimum Operating Temperature:
-20°C
Number of Contacts:
1
