Maximum Voltage:
240 V ac/dc
Width:
35mm
Supply Voltage:
12 → 240 V ac/dc
Current Maximum:
8 A
Time Range:
1 → 10 min, 1 → 10 s, 1 → 100 h
Mode of Operation:
A, AC, AT, B, BW, C, D, Di, Ht
Number of Timer Functions:
Multi Function
Maximum Operating Temperature:
+60°C
Terminal Type:
11-Pin Connector
Time Increment:
Hours, Minutes, Seconds
Power Supply:
External
Switch Configuration:
DPDT
Contact Configuration:
DPDT
Length:
45mm
Minimum Voltage:
12 V ac/dc
Mounting Type:
Plug In
Depth:
78mm
Minimum Operating Temperature:
-20°C
Number of Contacts:
2
Contact Material:
Silver Alloy
HTSUS:
8479.90.9596
RoHS Status:
RoHS Compliant
Relay Type:
Mechanical Relay
Termination Style:
Plug In, 11 Pin (Octal)
Timing Initiate Method:
Input Voltage, Trigger Signal
Function:
Programmable (Multi-Function)
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Circuit:
DPDT (2 Form C)
Contact Rating @ Voltage:
10A @ 250VAC
Delay Time:
0.1 Sec ~ 100 Hrs
Timing Adjustment Method:
Hand Dial
Mounting Type:
Socketable
Series:
PU2R3
Voltage - Supply:
12 ~ 240VAC/DC
ECCN:
EAR99
