Vishay, VS-VSKT162/14PBF, Thyristor Module, IGBT, 160A 1400V, 7-Pin INT-A-PAK

VS-VSKT162-14PBF Vishay, VS-VSKT162/14PBF, Thyristor Module, IGBT, 160A 1400V, 7-Pin INT-A-PAK
Vishay

Product Information

Repetitive Peak Forward Blocking Voltage:
1400V
Repetitive Peak Reverse Voltage:
1400V
Dimensions:
94 x 35 x 30mm
Mounting Type:
Panel Mount
Surge Current Rating:
5.1kA
Repetitive Peak Off-State Current:
50mA
Rated Average On-State Current:
160A
Height:
30mm
Width:
35mm
Length:
94mm
Peak On-State Voltage:
1.54V
Package Type:
INT-A-PAK
Minimum Operating Temperature:
-40 °C
Maximum Holding Current:
200mA
Maximum Gate Trigger Current:
270mA
Thyristor Type:
IGBT
Maximum Operating Temperature:
+125 °C
Pin Count:
7
Maximum Gate Trigger Voltage:
4V
RoHs Compliant
Checking for live stock

This is Thyristor Module IGBT 160A 1400V 7-Pin INT-A-PAK manufactured by Vishay. The manufacturer part number is VS-VSKT162/14PBF. Moreover, it has a repetitive peak forward blocking voltage about 1400v . It has about 1400v repetitive reverse voltage . The given dimensions of the product include 94 x 35 x 30mm. The product is available in panel mount configuration. It has about 5.1ka surge current rating . Its repetitive peak off-state current is approximately 50ma . Moreover, it has about 160a rated average on-state current . In addition, the height is 30mm. Furthermore, the product is 35mm wide. Its accurate length is 94mm. It has a peak on-state voltage about 1.54v . The package is a sort of int-a-pak. Whereas, the minimum operating temperature of the product is -40 °c. The product has a maximum 200ma holding current . In addition, the product has a maximum 270ma gate trigger current . In addition, the product has a/an igbt type thyristor . It has a maximum operating temperature of +125 °c. It contains 7 pins. Moreover, it has a maximum 4v gate trigger voltage .
