C&K KSL0M411LFT

KSL0M411LFT C&K
KSL0M411LFT
KSL0M411LFT
ET14634020
C&K

Product Information

Operating Force:
3 N
Actuator Length:
6.2mm
Illuminated:
No
Operating Temperature Range:
-40 → +85°C
Voltage Rating:
32V dc
Contact Current Rating:
50 mA @ 32 V dc
Minimum Operating Temperature:
-40°C
IP Rating:
IP60
Contact Configuration:
SPST
Actuator Type:
Side, Top
Mechanical Life:
100000Cycles
Maximum Operating Temperature:
+85°C
Terminal Type:
PC Terminal
Contact Material:
Silver Plated
Actuator Type:
Standard
Detailed Description:
Tactile Switch SPST-NO Top Actuated Through Hole
Operating Force:
300gf
Ingress Protection:
IP60 - Dust Tight
Outline:
7.40mm x 7.40mm
Mounting Type:
Through Hole
Series:
KSL
Switch Function:
Off-Mom
Termination Style:
PC Pin
Actuator Height off PCB, Vertical:
9.90mm
Packaging:
Bulk
Operating Temperature:
-40°C ~ 90°C
Actuator Orientation:
Top Actuated
Switch Travel:
0.60mm
Circuit:
SPST-NO
Contact Rating @ Voltage:
0.05A @ 32VDC
Illumination:
Non-Illuminated
Mechanical Life:
100,000 Cycles
Customer Reference:
Manufacturer:
C&K
RoHs Compliant
Checking for live stock

This is manufactured by C&K. The manufacturer part number is KSL0M411LFT. It has a 3 n of operating force. The actuator is a 6.2mm long. Illumination Option no. The product has -40 → +85°c of operating temperature range. Moreover, the product has a nominal 32v dc voltage rating. The rated contact current is 50 ma @ 32 v dc. Whereas, the minimum operating temperature of the product is -40°c. It is IP rated with ip60. The contact is equipped with spst configuration. The product carries side, top actuator. The product also provide mechanical stability with 100000cycles. It has a maximum operating temperature of +85°c. The terminal is a pc terminal type. The product is made from sturdy silver plated materials. The product carries standard actuator. It features tactile switch spst-no top actuated through hole. It has a 300gf of operating force. It is IP rated with ip60 - dust tight. The given outline of the product is 7.40mm x 7.40mm. The product is available in through hole configuration. The product ksl, is a highly preferred choice for users. It is designed as a off-mom switching function. Moreover, it has pc pin terminal style. Features 9.90mm actuator vertical height off PCB. In addition, bulk is the available packaging type of the product. The product has -40°c ~ 90°c operating temperature range. The actuator is adjusted at top actuated. The product has a switching travel of 0.60mm. It has an integral spst-no circuit. The given contact rating of the product and its voltage includes 0.05a @ 32vdc. Is this product illuminated? non-illuminated. The product also provide mechanical stability with 100,000 cycles. The c&k's product offers user-desired applications.
