Operating Force:
1.76 N
Actuator Length:
0.7mm
Dimensions:
10.8 x 10.8mm
Mounting Type:
PCB
Voltage Rating:
24V dc
Contact Current Rating:
50 mA
Minimum Operating Temperature:
-25°C
Operating Temperature Range:
-25 → +70°C
Contact Configuration:
Single Pole Single Throw (SPST)
Width:
10.8mm
Length:
10.8mm
Actuator Type:
Flat Button
Switch Operation:
Off-On (Momentary)
Maximum Operating Temperature:
+70°C
Terminal Type:
PC Pin
Contact Material:
Brass (Stationary), Stainless Steel (Movable)
Operating Force:
176gf
HTSUS:
8536.50.9031
RoHS Status:
ROHS3 Compliant
Termination Style:
PC Pin
Actuator Height off PCB, Vertical:
-
Operating Temperature:
-25°C ~ 70°C
Actuator Orientation:
Side Actuated
Mechanical Life:
5,000,000 Cycles
REACH Status:
REACH Unaffected
edacadModel:
JB15FH Models
edacadModelUrl:
/en/models/1054527
Illumination Type, Color:
-
Outline:
10.80mm x 6.54mm
Package:
Tray
Switch Function:
Off-Mom
Actuator Length, Right Angle:
1.46mm
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Circuit:
SPST-NO
Contact Rating @ Voltage:
0.05A @ 24VDC
standardLeadTime:
30 Weeks
Ingress Protection:
IP67 - Dust Tight, Waterproof
Features:
Process Sealed
Mounting Type:
Through Hole, Right Angle
Series:
JB
Switch Travel:
0.25mm
Actuator Type:
Round Button
Illumination:
Non-Illuminated
Illumination Voltage (Nominal):
-
Actuator Material:
Polybutylene Terephthalate (PBT)
Base Product Number:
-
ECCN:
EAR99
