Bourns Inc. PAD002-T764113S

PAD002-T764113S Bourns Inc.
Bourns Inc.

Product Information

Style:
-
HTSUS:
8504.31.2000
RoHS Status:
ROHS3 Compliant
Inductance @ Frequency:
475µH @ 100kHz
Operating Temperature:
-40°C ~ 125°C
Voltage - Primary:
-
Height - Seated (Max):
0.157" (3.99mm)
Type:
For DC/DC Converters
REACH Status:
REACH Unaffected
Applications:
Forward, Push-Pull Converters
Chipset Manufacturer:
-
Footprint:
0.388" L x 0.258" W (9.85mm x 6.55mm)
Package:
Tape & Reel (TR)
Voltage - Auxiliary:
-
Size / Dimension:
0.280" L x 0.258" W (7.10mm x 6.55mm)
standardLeadTime:
28 Weeks
Voltage - Isolation:
3100Vrms
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Mounting Type:
Surface Mount
Intended Chipset:
-
Series:
PAD00x-T764
Frequency:
-
ECCN:
EAR99
Checking for live stock

This is manufactured by Bourns Inc.. The manufacturer part number is PAD002-T764113S. It is assigned with possible HTSUS value of 8504.31.2000. The product is rohs3 compliant. Typical inductance of 475µh @ 100khz. The product has -40°c ~ 125°c operating temperature range. It has the maximum seated height of 0.157" (3.99mm). It comes in for dc/dc converters configuration. In addition, it is reach unaffected. The product is widely employed in forward, push-pull converters. Footprint Options include 0.388" l x 0.258" w (9.85mm x 6.55mm). It is shipped in tape & reel (tr) package . The product's diameters include 0.280" l x 0.258" w (7.10mm x 6.55mm). It has a long 28 weeks standard lead time. 3100vrms of isolation voltage. Its typical moisture sensitivity level is 1 (unlimited). The product is available in surface mount configuration. The product pad00x-t764, is a highly preferred choice for users. The product is designated with the ear99 code number.

pdf icon
Mult Series Manufacturing Site Relocation 10/Jan/2024(PCN Assembly/Origin)
pdf icon
PAD00x-T764 Series Datasheet(Datasheets)
pdf icon
PAD00x-T764 Series Design 21/Feb/2023(PCN Design/Specification)

Reviews

  • Be the first to review.
Don’t hesitate to ask questions for better clarification.


FAQs

Yes. You can also search PAD002-T764113S on website for other similar products.
We accept all major payment methods for all products including ET22281936. Please check your shopping cart at the time of order.
You can order Bourns Inc. brand products with PAD002-T764113S directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Switching Converter, SMPS Transformers category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Bourns Inc. PAD002-T764113S. You can also check on our website or by contacting our customer support team for further order details on Bourns Inc. PAD002-T764113S.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET22281936 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Bourns Inc." products on our website by using Enrgtech's Unique Manufacturing Part Number ET22281936.
Yes. We ship PAD002-T764113S Internationally to many countries around the world.
