Dimensions:
58 x 35.6 x 90mm
Mounting Type:
DIN Rail
Series:
VAL-MS 320/1+1
Length:
58mm
Height:
90mm
Depth:
35.6mm
Minimum Operating Temperature:
-40°C
Maximum Voltage Rating:
240 V ac, 415 V ac
Maximum Surge Current:
40kA
Maximum Operating Temperature:
+80°C
Suppressor Type:
Surge Arrester
HTSUS:
8536.30.8000
RoHS Status:
RoHS Compliant
Voltage - Continuous Operating (Max) (MCOV):
640VAC
Operating Temperature:
-40°C ~ 80°C
Approval Agency:
CB, CCA, CSA, cUL, cULus, EAC, KEMA-KEUR, OVE, UL
Type:
Type 2
Form:
Module Only
title:
2804380
Voltage - Protection Level (VP) (2416):
1.8 kV
edacadModel:
2804380 Models
Current - Discharge (Nom) (8/20µS):
20 kA
edacadModelUrl:
/en/models/4484035
Manufacturer:
Phoenix Contact
Moisture Sensitivity Level (MSL):
1 (Unlimited)
standardLeadTime:
4 Weeks
Current - Short Circuit Rating (SCCR):
25 kA
Features:
-
Mounting Type:
DIN Rail
Series:
-
Packaging:
Bulk
Current - Discharge (Max) (8/20µS):
40 kA
Number of Poles:
2
ECCN:
EAR99
