Inductor 0402 12nH 5 0.64A SMD

CW105550A-12NJ Inductor 0402 12nH 5 0.64A SMD
Bourns

Product Information

Maximum DC Resistance:
120mΩ
Inductor Construction:
Wire-Wound
Dimensions:
1 x 0.55 x 0.5mm
Shielded:
No
Series:
CW105550A
Minimum Operating Temperature:
-40°C
Minimum Quality Factor:
26
Length:
1mm
Height:
0.5mm
Maximum DC Current:
640mA
Depth:
0.55mm
Core Material:
Ceramic
Inductance:
12 nH
Maximum Self Resonant Frequency:
3.6GHz
Maximum Operating Temperature:
+125°C
Tolerance:
±5%
Automotive Standard:
AEC-Q200
Package/Case:
0402 (1005M)
RoHs Compliant
Checking for live stock

This is Inductor 0402 12nH 5 0.64A SMD manufactured by Bourns. The manufacturer part number is CW105550A-12NJ. It allows up to 120mω maximum DC resistance. The inductor is designed as wire-wound inductor. The given dimensions of the product include 1 x 0.55 x 0.5mm. Shielding Options no. The product cw105550a, is a highly preferred choice for users. Whereas, the minimum operating temperature of the product is -40°c. It has minimum 26 quality factors. Its accurate length is 1mm. In addition, the height is 0.5mm. While it carries 640ma of maximum DC current. The product comes in 0.55mm depth. The core is manufactured from highly durable and reliable ceramic materials. The product has a 12 nh inductance value. It provides 3.6ghz of maximum self-resonant frequency. It has a maximum operating temperature of +125°c. It features ±5% of tolerance value. The product complies with automotive standard - aec-q200. Concerning its package and casing, it is 0402 (1005m).

pdf icon
Datasheet CW105550A-12NJ(Technical Reference)
