Wire Wound Ferrite Core 3.2 x 2.5mm 15uH

NLCV32T-150K-EF Wire Wound Ferrite Core 3.2 x 2.5mm 15uH
TDK

Product Information

Maximum DC Resistance:
728mΩ
Inductor Construction:
Wire-Wound
Dimensions:
3.2 x 2.5 x 2.2mm
Shielded:
Yes
Series:
NLCV-EF
Minimum Operating Temperature:
-40°C
Minimum Quality Factor:
15
Length:
3.2mm
Height:
2.2mm
Maximum DC Current:
370mA
Depth:
2.5mm
Core Material:
Ferrite
Inductance:
15 μH
Maximum Self Resonant Frequency:
26MHz
Maximum Operating Temperature:
+105°C
Tolerance:
±10%
Moulded:
Yes
Package/Case:
1210 (3225M)
RoHs Compliant
Checking for live stock

This is Wire Wound Ferrite Core 3.2 x 2.5mm 15uH manufactured by TDK. The manufacturer part number is NLCV32T-150K-EF. It allows up to 728mω maximum DC resistance. The inductor is designed as wire-wound inductor. The given dimensions of the product include 3.2 x 2.5 x 2.2mm. Shielding Options yes. The product nlcv-ef, is a highly preferred choice for users. Whereas, the minimum operating temperature of the product is -40°c. It has minimum 15 quality factors. Its accurate length is 3.2mm. In addition, the height is 2.2mm. While it carries 370ma of maximum DC current. The product comes in 2.5mm depth. The core is manufactured from highly durable and reliable ferrite materials. The product has a 15 μh inductance value. It provides 26mhz of maximum self-resonant frequency. It has a maximum operating temperature of +105°c. It features ±10% of tolerance value. In addition, it is moulded yes . Concerning its package and casing, it is 1210 (3225m).

pdf icon
Datasheet NLCV32T-150K-EF(Technical Reference)
