Wire Wound Ferrite Core 2.5 x 2mm 1.5uH

NLCV25T-1R5M-EF Wire Wound Ferrite Core 2.5 x 2mm 1.5uH
TDK

Product Information

Maximum DC Resistance:
546mΩ
Inductor Construction:
Wire-Wound
Dimensions:
2.5 x 2 x 1.8mm
Shielded:
Yes
Series:
NLCV-EF
Minimum Operating Temperature:
-40°C
Minimum Quality Factor:
20
Length:
2.5mm
Height:
1.8mm
Maximum DC Current:
435mA
Depth:
2mm
Core Material:
Ferrite
Inductance:
1.5 μH
Maximum Self Resonant Frequency:
165MHz
Maximum Operating Temperature:
+105°C
Tolerance:
±20%
Moulded:
Yes
Package/Case:
1008 (2520M)
RoHs Compliant
Checking for live stock

This is Wire Wound Ferrite Core 2.5 x 2mm 1.5uH manufactured by TDK. The manufacturer part number is NLCV25T-1R5M-EF. It allows up to 546mω maximum DC resistance. The inductor is designed as wire-wound inductor. The given dimensions of the product include 2.5 x 2 x 1.8mm. Shielding Options yes. The product nlcv-ef, is a highly preferred choice for users. Whereas, the minimum operating temperature of the product is -40°c. It has minimum 20 quality factors. Its accurate length is 2.5mm. In addition, the height is 1.8mm. While it carries 435ma of maximum DC current. The product comes in 2mm depth. The core is manufactured from highly durable and reliable ferrite materials. The product has a 1.5 μh inductance value. It provides 165mhz of maximum self-resonant frequency. It has a maximum operating temperature of +105°c. It features ±20% of tolerance value. In addition, it is moulded yes . Concerning its package and casing, it is 1008 (2520m).

pdf icon
Datasheet NLCV25T-1R5M-EF(Technical Reference)
