Wire Wound Ferrite Core 2.5 x 2mm 33uH

TDK

Product Information

Maximum DC Resistance:
5.46Ω
Inductor Construction:
Wire-Wound
Dimensions:
2.5 x 2 x 1.8mm
Shielded:
Yes
Series:
NLCV-EF
Minimum Operating Temperature:
-40°C
Minimum Quality Factor:
30
Length:
2.5mm
Height:
1.8mm
Maximum DC Current:
120mA
Depth:
2mm
Core Material:
Ferrite
Inductance:
33 μH
Maximum Self Resonant Frequency:
16MHz
Maximum Operating Temperature:
+105°C
Tolerance:
±10%
Moulded:
Yes
Package/Case:
1008 (2520M)
RoHs Compliant
Checking for live stock

This is Wire Wound Ferrite Core 2.5 x 2mm 33uH manufactured by TDK. The manufacturer part number is NLCV25T-330K-EF. It allows up to 5.46ω maximum DC resistance. The inductor is designed as wire-wound inductor. The given dimensions of the product include 2.5 x 2 x 1.8mm. Shielding Options yes. The product nlcv-ef, is a highly preferred choice for users. Whereas, the minimum operating temperature of the product is -40°c. It has minimum 30 quality factors. Its accurate length is 2.5mm. In addition, the height is 1.8mm. While it carries 120ma of maximum DC current. The product comes in 2mm depth. The core is manufactured from highly durable and reliable ferrite materials. The product has a 33 μh inductance value. It provides 16mhz of maximum self-resonant frequency. It has a maximum operating temperature of +105°c. It features ±10% of tolerance value. In addition, it is moulded yes . Concerning its package and casing, it is 1008 (2520m).

pdf icon
Datasheet NLCV25T-330K-EF(Technical Reference)
