Wire Wound Ferrite Core 3.2 x 2.5mm 1uH

NLCV32T-1R0M-EF Wire Wound Ferrite Core 3.2 x 2.5mm 1uH
TDK

Product Information

Maximum DC Resistance:
78mΩ
Inductor Construction:
Wire-Wound
Dimensions:
3.2 x 2.5 x 2.2mm
Shielded:
Yes
Series:
NLCV-EF
Minimum Operating Temperature:
-40°C
Minimum Quality Factor:
10
Length:
3.2mm
Height:
2.2mm
Maximum DC Current:
1A
Depth:
2.5mm
Core Material:
Ferrite
Inductance:
1 μH
Maximum Self Resonant Frequency:
100MHz
Maximum Operating Temperature:
+105°C
Tolerance:
±20%
Moulded:
Yes
Package/Case:
1210 (3225M)
RoHs Compliant
Checking for live stock

This is Wire Wound Ferrite Core 3.2 x 2.5mm 1uH manufactured by TDK. The manufacturer part number is NLCV32T-1R0M-EF. It allows up to 78mω maximum DC resistance. The inductor is designed as wire-wound inductor. The given dimensions of the product include 3.2 x 2.5 x 2.2mm. Shielding Options yes. The product nlcv-ef, is a highly preferred choice for users. Whereas, the minimum operating temperature of the product is -40°c. It has minimum 10 quality factors. Its accurate length is 3.2mm. In addition, the height is 2.2mm. While it carries 1a of maximum DC current. The product comes in 2.5mm depth. The core is manufactured from highly durable and reliable ferrite materials. The product has a 1 μh inductance value. It provides 100mhz of maximum self-resonant frequency. It has a maximum operating temperature of +105°c. It features ±20% of tolerance value. In addition, it is moulded yes . Concerning its package and casing, it is 1210 (3225m).

pdf icon
Datasheet NLCV32T-1R0M-EF(Technical Reference)
