Wurth WE-MAPI Series Type 3020 Shielded Wire-wound SMD Inductor with a Magnetic Iron Alloy Core, 10 μH ±20% Wire-Wound

74438336100 Wurth WE-MAPI Series Type 3020 Shielded Wire-wound SMD Inductor with a Magnetic Iron Alloy Core, 10 μH ±20% Wire-Wound
Wurth Elektronik

Product Information

Maximum DC Resistance:
322mΩ
Inductor Construction:
Wire-Wound
Dimensions:
3 x 3 x 2mm
Shielded:
Yes
Series:
WE-MAPI
Length:
3mm
Height:
2mm
Maximum DC Current:
1.2A
Depth:
3mm
Core Material:
Magnetic Iron Alloy
Inductance:
10 μH
Maximum Self Resonant Frequency:
18MHz
Maximum Operating Temperature:
+125°C
Tolerance:
±20%
Minimum Operating Temperature:
-40°C
Package/Case:
3020
RoHs Compliant
Checking for live stock

This is Wurth WE-MAPI Series Type 3020 Shielded Wire-wound SMD Inductor with a Magnetic Iron Alloy Core 10 μH ±20% Wire-Wound manufactured by Wurth Elektronik. The manufacturer part number is 74438336100. It allows up to 322mω maximum DC resistance. The inductor is designed as wire-wound inductor. The given dimensions of the product include 3 x 3 x 2mm. Shielding Options yes. The product we-mapi, is a highly preferred choice for users. Its accurate length is 3mm. In addition, the height is 2mm. While it carries 1.2a of maximum DC current. The product comes in 3mm depth. The core is manufactured from highly durable and reliable magnetic iron alloy materials. The product has a 10 μh inductance value. It provides 18mhz of maximum self-resonant frequency. It has a maximum operating temperature of +125°c. It features ±20% of tolerance value. Whereas, the minimum operating temperature of the product is -40°c. Concerning its package and casing, it is 3020.

pdf icon
WE eiSos Embedded Flyer(Technical Reference)
pdf icon
Voids in Bottom Termination Components (BTC) - ANP036 Application Note(Technical Reference)
pdf icon
Ideal Power Inductors for Energy Efficient Applications - ANP031 Application Note(Technical Reference)
pdf icon
Datasheet(Technical Reference)
pdf icon
Accurate Inductor Loss Determination - Application Note(Technical Reference)
pdf icon
Application Note - The Sham of the High Rated Current(Technical Reference)
