Vishay IHLP-3232DZ-01 Series Type 3232 Shielded Wire-wound SMD Inductor with a Metal Composite Core, 4.7 μH ±20%

Enrgtech Part No: ET14079843
|
Manufacturer Part No:
IHLP3232DZER4R7M01
|
Manufacturer: Vishay

IHLP3232DZER4R7M01 Vishay IHLP-3232DZ-01 Series Type 3232 Shielded Wire-wound SMD Inductor with a Metal Composite Core, 4.7 μH ±20%

Product Information

Maximum DC Resistance:

32mΩ

Inductor Construction:

Wire-Wound

Dimensions:

8.64 x 8.18 x 4mm

Shielded:

Yes

Series:

IHLP-3232DZ-01

Length:

8.64mm

Height:

4mm

Maximum DC Current:

7.25A

Depth:

8.18mm

Core Material:

Metal Composite

Inductance:

4.7 μH

Maximum Self Resonant Frequency:

20MHz

Checking for live stock

This is IHLP-3232DZ-01 Series Type 3232 Shielded Wire-wound SMD Inductor with a Metal Composite Core 4.7 μH ±20% manufactured by Vishay. The manufacturer part number is IHLP3232DZER4R7M01. It allows up to 32mω maximum DC resistance. The inductor is designed as wire-wound inductor. The given dimensions of the product include 8.64 x 8.18 x 4mm. Shielding Options yes. The product ihlp-3232dz-01, is a highly preferred choice for users. Its accurate length is 8.64mm. In addition, the height is 4mm. While it carries 7.25a of maximum DC current. The product comes in 8.18mm depth. The core is manufactured from highly durable and reliable metal composite materials. The product has a 4.7 μh inductance value. It provides 20mhz of maximum self-resonant frequency. It has a maximum operating temperature of +125°c. It features ±20% of tolerance value. Whereas, the minimum operating temperature of the product is -55°c. Concerning its package and casing, it is 3232.
