Vishay IHLP-3232DZ-01 Series Type 3232 Shielded Wire-wound SMD Inductor with a Metal Composite Core, 1 μH ±20%

Enrgtech Part No: ET13922236
|
Manufacturer Part No:
IHLP3232DZER1R0M01
|
Manufacturer: Vishay

IHLP3232DZER1R0M01 Vishay IHLP-3232DZ-01 Series Type 3232 Shielded Wire-wound SMD Inductor with a Metal Composite Core, 1 μH ±20%

Product Information

Maximum DC Resistance:

5.78mΩ

Inductor Construction:

Wire-Wound

Dimensions:

8.64 x 8.18 x 4mm

Shielded:

Yes

Series:

IHLP-3232DZ-01

Length:

8.64mm

Height:

4mm

Maximum DC Current:

18A

Depth:

8.18mm

Core Material:

Metal Composite

Inductance:

1 μH

Maximum Self Resonant Frequency:

42MHz

Checking for live stock

This is IHLP-3232DZ-01 Series Type 3232 Shielded Wire-wound SMD Inductor with a Metal Composite Core 1 μH ±20% manufactured by Vishay. The manufacturer part number is IHLP3232DZER1R0M01. It allows up to 5.78mω maximum DC resistance. The inductor is designed as wire-wound inductor. The given dimensions of the product include 8.64 x 8.18 x 4mm. Shielding Options yes. The product ihlp-3232dz-01, is a highly preferred choice for users. Its accurate length is 8.64mm. In addition, the height is 4mm. While it carries 18a of maximum DC current. The product comes in 8.18mm depth. The core is manufactured from highly durable and reliable metal composite materials. The product has a 1 μh inductance value. It provides 42mhz of maximum self-resonant frequency. It has a maximum operating temperature of +125°c. It features ±20% of tolerance value. Whereas, the minimum operating temperature of the product is -55°c. Concerning its package and casing, it is 3232.

Application Note(Technical Reference)

Power Inductors Capabilities(Technical Reference)

Power Inductors 101(Technical Reference)

Datasheet(Technical Reference)

Did You Know?(Technical Reference)

IHLP Selection Example(Technical Reference)

Power Inductors Infograph(Technical Reference)
