Phoenix Contact MINI COMBICON MC Series 3.5mm Pitch Pluggable Terminal Block, PCB Header, 5 Way
Product Information
Current Rating:
8.0A
Mounting Type:
Through Hole
Voltage Rating:
250.0 V
Series:
COMBICON Control
Colour:
Black
Termination Method:
Solder
Pluggable Terminal Block Type:
Header
Number of Rows:
1
Pitch:
3.5mm
Number of Contacts:
5
Body Orientation:
Right Angle
HTSUS:
8536.69.4040
Positions Per Level:
5
Termination Style:
Solder
Housing Material:
Liquid Crystal Polymer (LCP)
Operating Temperature:
-40°C ~ 100°C
Screw Size:
-
Wire Strip Length:
-
Type:
Header, Male Pins, Shrouded (4 Side)
Number of Positions:
5
Contact Tail Length:
0.079" (2.00mm)
Wire Gauge or Range - mm²:
-
Plug Wire Entry:
-
Insulation Height:
0.272" (6.91mm)
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Current - IEC:
8A
Number of Levels:
1
Wire Gauge or Range - AWG:
-
Voltage - UL:
300 V
Torque - Screw:
-
standardLeadTime:
8 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
160 V
Ingress Protection:
-
Features:
Flange
Mounting Type:
Through Hole
Color:
Black
Series:
COMBICON MC
Header Orientation:
90°, Right Angle
Current - UL:
8 A
Pitch:
0.138" (3.50mm)
ECCN:
EAR99
Contact Material:
Copper Alloy
Checking for live stock
FAQs
Yes. You can also search 1789449 on website for other similar products.
We accept all major payment methods for all products including ET13857876. Please check your shopping cart at the time of order.
You can order Phoenix Contact brand products with 1789449 directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Standard Terminal Blocks category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Phoenix Contact MINI COMBICON MC Series 3.5mm Pitch Pluggable Terminal Block, PCB Header, 5 Way. You can also check on our website or by contacting our customer support team for further order details on Phoenix Contact MINI COMBICON MC Series 3.5mm Pitch Pluggable Terminal Block, PCB Header, 5 Way.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET13857876 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Phoenix Contact" products on our website by using Enrgtech's Unique Manufacturing Part Number ET13857876.
Yes. We ship 1789449 Internationally to many countries around the world.
This is MINI COMBICON MC Series 3.5mm Pitch Pluggable Terminal Block PCB Header 5 Way manufactured by Phoenix Contact. The manufacturer part number is 1789449. The product has a current rating of 8.0a. The product is available in through hole configuration. Moreover, the product has a nominal 250.0 v voltage rating. The product combicon control, is a highly preferred choice for users. It has a decent black colour. It allows solder termination method. It comes in 1 of rows. Moreover, the product is 3.5mm. The product contains 5 contacts. It has right angle body orientation. It is assigned with possible HTSUS value of 8536.69.4040. It has 5 positions each level. Moreover, it has solder terminal style. The product also features robust liquid crystal polymer (lcp) housing material. The product has -40°c ~ 100°c operating temperature range. It comes in header, male pins, shrouded (4 side) configuration. The product carries possible position value of 5. The typical tail length of the product is [Contact Tail Lenght]. 0.272" (6.91mm) of insulation height. It carries ul94 v-0 of material flammability rating. It is shipped in bulk package . An IEC current of 8a. The product carries 1 levels. While 300 v is the typical voltage of the product. It has a long 8 weeks standard lead time. The mating finish of the contact is tin. The nominal voltage of the product is 160 v. The splendid features of the product include flange. It has a classic black colour. The product combicon mc, is a highly preferred choice for users. The product has a 90°, right angle of a header orientation. The typical current includes 8 a. Moreover, the product is 0.138" (3.50mm). The product is designated with the ear99 code number. The product is made from sturdy copper alloy materials.
