Row Width:
15.24mm
Number of Contacts:
32
Current Rating:
1A
Dimensions:
55.2 x 32 x 6.9mm
Mounting Type:
Through Hole
Voltage Rating:
1 kV ac
Series:
2321285
Termination Method:
Solder
Length:
55.2mm
Housing Material:
Glass Filled Polysulfone
Width:
32mm
Depth:
6.9mm
Contact Plating:
Gold over Nickel
Pitch:
2.54mm
Contact Material:
Beryllium Copper
Maximum Operating Temperature:
+125°C
Minimum Operating Temperature:
-55°C
Orientation:
Straight
HTSUS:
8536.69.4040
RoHS Status:
RoHS Compliant
Convert From (Adapter End):
DIP, 0.6" (15.24mm) Row Spacing
Housing Material:
Polysulfone (PSU), Glass Filled
Operating Temperature:
-55°C ~ 125°C
Contact Finish Thickness - Post:
30.0µin (0.76µm)
Contact Material - Mating:
Beryllium Copper
Contact Finish - Mating:
Gold
Convert To (Adapter End):
DIP, 0.6" (15.24mm) Row Spacing
Number of Pins:
32
Material Flammability Rating:
UL94 V-0
Contact Material - Post:
Beryllium Copper
Package:
Box
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Termination:
Solder
Current Rating (Amps):
1 A
Pitch - Mating:
0.100" (2.54mm)
Features:
Closed Frame
Mounting Type:
Through Hole
Termination Post Length:
0.130" (3.30mm)
Series:
Textool™
ECCN:
EAR99
Contact Finish Thickness - Mating:
30.0µin (0.76µm)
Pitch - Post:
0.100" (2.54mm)
Board Material:
-
Base Product Number:
232
Contact Finish - Post:
Gold
