Vishay Single Layer Ceramic Capacitor (SLCC) 2.5nF 15kV dc -20 → +80% Z5U Dielectric 615R Series

615R100GAD25 Vishay Single Layer Ceramic Capacitor (SLCC) 2.5nF 15kV dc -20 → +80% Z5U Dielectric 615R Series
Vishay

Product Information

Diameter:
19.1mm
Suppression Class:
Class II
Dimensions:
19.1 (Dia.) x 51.1mm
Mounting Type:
Through Hole
Series:
615R
Dissipation Factor:
2%
Capacitance:
2.5nF
Depth:
8.9mm
Voltage:
10kV dc
Minimum Operating Temperature:
-25°C
Dielectric:
Z5U
Maximum Operating Temperature:
+105°C
Tolerance:
-20 → +80%
Terminal Type:
Radial
Dielectric Material Family:
Ceramic
RoHs Compliant
Checking for live stock

This is Single Layer Ceramic Capacitor (SLCC) 2.5nF 15kV dc -20 → +80% Z5U Dielectric 615R Series manufactured by Vishay. The manufacturer part number is 615R100GAD25. Its diameter is 19.1mm. It is a class ii suppression class. The given dimensions of the product include 19.1 (dia.) x 51.1mm. The product is available in through hole configuration. The product 615r, is a highly preferred choice for users. It provides a dissipation factor of 2%. It provides a 2.5nf of capacitance value. The product comes in 8.9mm depth. It carries a 10kv dc of voltage. Whereas, the minimum operating temperature of the product is -25°c. The dielectric options include z5u. It has a maximum operating temperature of +105°c. It features -20 → +80% of tolerance value. The terminal is a radial type. Whereas its dielectric material family is ceramic.

pdf icon
Vishay High Voltage Ceramic Capacitor Datasheet(Technical Reference)
