Infineon Technologies IRLHS2242TRPBF

IRLHS2242TRPBF Infineon Technologies
Infineon Technologies

Product Information

FET Feature:
-
HTSUS:
8541.29.0095
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-55°C ~ 150°C (TJ)
Package / Case:
6-PowerVDFN
Rds On (Max) @ Id, Vgs:
31mOhm @ 8.5A, 4.5V
Gate Charge (Qg) (Max) @ Vgs:
12 nC @ 10 V
Vgs(th) (Max) @ Id:
1.1V @ 10µA
REACH Status:
REACH Unaffected
edacadModel:
IRLHS2242TRPBF Models
FET Type:
P-Channel
Drive Voltage (Max Rds On, Min Rds On):
2.5V, 4.5V
edacadModelUrl:
/en/models/2639556
Drain to Source Voltage (Vdss):
20 V
Vgs (Max):
±12V
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Power Dissipation (Max):
2.1W (Ta), 9.6W (Tc)
standardLeadTime:
12 Weeks
Input Capacitance (Ciss) (Max) @ Vds:
877 pF @ 10 V
Mounting Type:
Surface Mount
Series:
HEXFET®
Supplier Device Package:
6-PQFN (2x2) (DFN2020)
Packaging:
Tape & Reel (TR)
Current - Continuous Drain (Id) @ 25°C:
7.2A (Ta), 15A (Tc)
Technology:
MOSFET (Metal Oxide)
Base Product Number:
IRLHS2242
ECCN:
EAR99
Checking for live stock

This is manufactured by Infineon Technologies. The manufacturer part number is IRLHS2242TRPBF. It is assigned with possible HTSUS value of 8541.29.0095. The product is rohs3 compliant. The product has -55°c ~ 150°c (tj) operating temperature range. Moreover, the product comes in 6-powervdfn. It has a maximum Rds On and voltage of 31mohm @ 8.5a, 4.5v. The maximum gate charge and given voltages include 12 nc @ 10 v. The typical Vgs (th) (max) of the product is 1.1v @ 10µa. In addition, it is reach unaffected. It carries FET type p-channel. The drive voltage (maximum and minimum Rds On) of the product includes 2.5v, 4.5v. The product has a 20 v drain to source voltage. The maximum Vgs rate is ±12v. Its typical moisture sensitivity level is 1 (unlimited). The product carries maximum power dissipation 2.1w (ta), 9.6w (tc). It has a long 12 weeks standard lead time. The product's input capacitance at maximum includes 877 pf @ 10 v. The product is available in surface mount configuration. The product hexfet®, is a highly preferred choice for users. 6-pqfn (2x2) (dfn2020) is the supplier device package value. In addition, tape & reel (tr) is the available packaging type of the product. The continuous current drain at 25°C is 7.2a (ta), 15a (tc). This product use mosfet (metal oxide) technology. Moreover, it corresponds to irlhs2242, a base product number of the product. The product is designated with the ear99 code number.
