American Wire Gauge:
22 AWG
Number of Strands:
19
Standards Met:
EU Low Voltage Directive 2014/35/EC, UL AWM 11540
Voltage Rating:
600 V ac
Conductor Material:
Nickel Plated Copper
Series:
ThermoThin
Wire Style:
AWM/STYLE 11540
Operating Temperature Range:
-150 → +300 °C
Core Strands:
19/34
Sheath Colour:
Grey
Insulation Wall Thickness:
0.14mm
Length:
30m
Resistant To:
Chemicals, Sunlight, Water
Insulation Material:
Fluoropolymer
Outer Diameter:
1.04mm
Minimum Operating Temperature:
-150°C
Maximum Operating Temperature:
+300°C
Type:
Hook-Up Wire
Size of Strands:
0.16 mm, 34 AWG
Cross Sectional Area:
0.38 mm²
Ratings:
UL Style 11540
HTSUS:
8544.49.3080
RoHS Status:
ROHS3 Compliant
Jacket (Insulation) Material:
Fluoropolymer
Conductor Strand:
19/34
Operating Temperature:
-150°C ~ 300°C
REACH Status:
REACH Unaffected
Package:
Spool
Wire Gauge:
22 AWG
Jacket (Insulation) Thickness:
0.006" (0.15mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
100.0' (30.5m)
Features:
Chemical Resistant, High Temperature, UV Resistant
Jacket (Insulation) Diameter:
0.041" (1.04mm)
Conductor Material:
Copper, Nickel Coated
Series:
ThermoThin
Cable Type:
Hook-Up
Voltage:
600V
ECCN:
EAR99
Base Product Number:
2922
Jacket Color:
Slate
