This is PCB Mount Signal Relay 2.5V dc Coil 2A Switching Current DPDT manufactured by TE Connectivity. The manufacturer part number is IM02JR 1-1462037-1. The given dimensions of the product include 10 x 6 x 5.65mm. The coil voltage of the product is 2.5v dc. It consists of single coils. The terminal is a surface mount type. It holds up to 145 ω coil resistance. Robust coil power of 140mw. While it carries 220v dc of maximum DC switching voltage. It has a maximum operating temperature of +85°c. It is integrated with 2a switching current. The product has -40 → 85°c of operating temperature range. Latching Options - no. The contact is equipped with dpdt configuration. Its accurate length is 10mm. The splendid features of the product include j leg. The product is available in pcb mount configuration. The product axicom im, is a highly preferred choice for users. The product comes in 6mm depth. In addition, the height is 5.65mm. It has a minimum 2 a DC switching current . It has a maximum AC switching voltage of 250v ac. Whereas, the minimum operating temperature of the product is -40°c. It has equipped with 2 poles. The product is made from sturdy gold plated materials.
For more information please check the datasheets.
