Omron PCB Mount Signal Relay, 5V dc Coil, 2A Switching Current, SPST

G5V-1-DC5 Omron PCB Mount Signal Relay, 5V dc Coil, 2A Switching Current, SPST
G5V-1 DC5
Omron

Product Information

Dimensions:
12.5 x 10 x 7.5mm
Electrical Life:
10^5 Operations
Application:
Signal
Terminal Type:
Through Hole
Coil Resistance:
167Ω
Coil Power:
150mW
Maximum Switching Voltage DC:
60V
Maximum Switching Power DC:
60 W
Isolation Coil To Contact:
3.5kV rms
Maximum Operating Temperature:
+70°C
Switching Current:
2A
Coil Voltage:
5V dc
Operating Temperature Range:
-40 → +70°C
Latching:
No
Contact Configuration:
SPDT
Length:
10mm
Features:
Conforms to FCC Part 68 Requirements, Bifurcated Contacts
Mounting Type:
PCB Mount
Series:
IM
Depth:
7.5mm
Height:
10mm
Maximum Switching Current DC:
2 A
Maximum Switching Voltage AC:
125V
Minimum Operating Temperature:
-40°C
Maximum Switching Power AC:
62.5VA
Number of Poles:
1
Contact Material:
Gold Plated
RoHs Compliant
Checking for live stock

This is PCB Mount Signal Relay 5V dc Coil 2A Switching Current SPST manufactured by Omron. The manufacturer part number is G5V-1 DC5. The given dimensions of the product include 12.5 x 10 x 7.5mm. The product offers long-lasting services of 10^5 operations. Applications Information involves signal. The terminal is a through hole type. It holds up to 167ω coil resistance. Robust coil power of 150mw. While it carries 60v of maximum DC switching voltage. It bears a maximum 60 w of DC switching power. The product has 3.5kv rms isolation coil to contact. It has a maximum operating temperature of +70°c. It is integrated with 2a switching current. The coil voltage of the product is 5v dc. The product has -40 → +70°c of operating temperature range. Latching Options - no. The contact is equipped with spdt configuration. Its accurate length is 10mm. The splendid features of the product include conforms to fcc part 68 requirements, bifurcated contacts. The product is available in pcb mount configuration. The product im, is a highly preferred choice for users. The product comes in 7.5mm depth. In addition, the height is 10mm. It has a minimum 2 a DC switching current . It has a maximum AC switching voltage of 125v. Whereas, the minimum operating temperature of the product is -40°c. It also features an AC switching power of 62.5va. It has equipped with 1 poles. The product is made from sturdy gold plated materials.

pdf icon
UL E41643(Technical Reference)
pdf icon
G5V-1 Datasheet(Technical Reference)
pdf icon
UL E41515(Technical Reference)
pdf icon
CSA 024825(Technical Reference)
