Dimensions:
10 x 6 x 5.65mm
Coil Voltage:
5V dc
Application:
Access & Transmission Equipment, Consumer Electronics, Industrial Controls, Measurement & Test Equipment, Medical Equipment, Modems, Office & Business Equipment, Optical Network Terminals, Telecommunication
Terminal Type:
Through Hole
Coil Resistance:
178Ω
Life:
100000000 (Mechanical) operations, 2500000 (Electrical) operations
Standards Met:
UL 508 File No. E 111441
Coil Power:
140mW
Maximum Switching Voltage DC:
220V
Maximum Switching Power DC:
60 W
Isolation Coil To Contact:
1.8kV rms
Maximum Operating Temperature:
+85°C
Switching Current:
2A
Operating Temperature Range:
-40 → +85°C
Latching:
No
Contact Configuration:
DPDT
Depth:
6mm
Relay Switching Classification:
General Purpose Relay
Features:
Bifurcated Contacts
Mounting Type:
Surface Mount
Series:
IM-E
Length:
10mm
Height:
5.65mm
Maximum Switching Current DC:
2 A
Maximum Switching Voltage AC:
250V
Minimum Operating Temperature:
-40°C
Maximum Switching Power AC:
62.5VA
Number of Poles:
2
Contact Material:
Gold Plated
