Dimensions:
10 x 5.2 x 7.2mm
Electrical Life:
100000 Operations Cycles
Terminal Type:
PCB Pin
Coil Resistance:
90Ω
Life:
100000 (Electrical) cycles, 50000000 (Mechanical) cycles
Coil Power:
100mW
Maximum Switching Voltage DC:
110V
Maximum Switching Power DC:
30 W
Isolation Coil To Contact:
1.5kV rms
Maximum Operating Temperature:
+85°C
Switching Current:
1A
Maximum Switching Current AC:
0.3 A
Coil Voltage:
3V dc
Operating Temperature Range:
-40 → +85°C
Latching:
No
Contact Configuration:
DPDT
Depth:
7.7mm
Features:
Compact Slim Body Saves Space, Increased Packaging Density, Sealed Construction allows Automatic Washing.
Mounting Type:
PCB Mount
Series:
FTR-C1
Length:
10.6mm
Height:
5.2mm
Maximum Switching Current DC:
1 A
Maximum Switching Voltage AC:
125V
Minimum Operating Temperature:
-40°C
Maximum Switching Power AC:
37.5VA
Number of Poles:
2
Contact Material:
Au Plated AgPd
