Dimensions:
20 x 9.9 x 9.9mm
Electrical Life:
5000000 Operation Cycles
Application:
Office Equipment, Telecommunications
Terminal Type:
PCB Pin
Coil Resistance:
11500Ω
Life:
10^8 (Mechanical) Operations, 5 x 10^5 (Electrical) Operations
Coil Power:
200mW
Maximum Switching Voltage DC:
220V dc
Maximum Switching Power DC:
60 W
Isolation Coil To Contact:
1.5kV rms
Maximum Operating Temperature:
+70°C
Switching Current:
3A
Coil Voltage:
48V dc
Operating Temperature Range:
-40 → +70°C
Latching:
No
Contact Configuration:
DPDT
Depth:
9.8mm
Features:
Suitable For Use In Difficult Environments, Gold Clad Twin Contacts Ensure High Reliability, Can Be Used With Automatic Solder And Automatic Wash Systems
Mounting Type:
PCB Mount
Series:
DS
Length:
20.2mm
Height:
9.9mm
Maximum Switching Current DC:
3 A
Maximum Switching Voltage AC:
250V ac
Minimum Operating Temperature:
-40°C
Maximum Switching Power AC:
125VA
Number of Poles:
2
Contact Material:
Gold Plated
