Dimensions:
15 x 7.5 x 9mm
Electrical Life:
10000000 Operations
Application:
Electronic Switching Systems, PBX, Telecommunications, Terminal Equipment
Coil Resistance:
64.3 Ω
Standards Met:
CSA, UL Recognized E73266
Coil Power:
140mW
Maximum Switching Voltage DC:
220V
Maximum Switching Power DC:
60 W
Isolation Coil To Contact:
1kV ac
Maximum Operating Temperature:
+85°C
Terminal Type:
PCB Pin
Maximum Switching Current AC:
2 A
Coil Voltage:
3 V dc
Operating Temperature Range:
-40 → +85°C
Contact Configuration:
DPDT
Length:
15mm
Relay Switching Classification:
Latching Relay
Features:
Compact and Lightweight, Low Magnetic Interference, Low Power Consumption
Mounting Type:
Surface Mount
Depth:
7.5mm
Height:
9mm
Maximum Switching Current DC:
2 A
Maximum Switching Voltage AC:
250V
Minimum Operating Temperature:
-40°C
Maximum Switching Power AC:
125 VA
Number of Poles:
1
Contact Material:
Silver Alloy
Must Release Voltage:
-
HTSUS:
8536.41.0020
RoHS Status:
ROHS3 Compliant
Coil Voltage:
3VDC
Termination Style:
Gull Wing
REACH Status:
REACH Unaffected
Operating Temperature:
-40°C ~ 85°C
Approval Agency:
CSA, TUV, UL
Coil Resistance:
64.3 Ohms
Coil Current:
46.7 mA
Coil Type:
Latching, Dual Coil
Switching Voltage:
250VAC, 220VDC - Max
Seal Rating:
-
edacadModel:
EE2-3TNUH-L Models
edacadModelUrl:
/en/models/4291076
Must Operate Voltage:
2.25 VDC
Manufacturer:
KEMET
Relay Type:
General Purpose
Load - Max Switching:
500VA, 440W
Contact Form:
DPDT (2 Form C)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Operate Time:
2 ms
Qualification:
-
standardLeadTime:
16 Weeks
Contact Rating (Current):
2 A
Features:
-
Mounting Type:
Surface Mount
Grade:
-
Series:
EE2
Release Time:
1 ms
Packaging:
Tape & Reel (TR)
Coil Insulation:
-
Contact Material:
Silver Alloy, Gold Alloy
Base Product Number:
EE2-3T
ECCN:
EAR99
