Standards Met:
Class I, CULus, Div. 2, Groups A, Groups B, Groups C, Groups D, Groups T4
Mounting Type:
DIN Rail
Operating Temperature Range:
-25 → +60 °C
Output Range:
0 → 10 V, 0 → 20 mA, 4 → 20 mA
Module Type:
Converter
Output Type:
Analogue
Input Range:
0 → 1 V, 0 → 10 mA, 0 → 10 V, 0 → 100 mV, 0 → 2 V, 0 → 20 mA, 0 → 20 V, 0 → 300 mV, 0 → 5 mA, 0 → 5 V, 0 → 500 mV, 0 → 60 mV, ±20 mA, ±5 mA, 2 → 10 V, 4 → 20 mA
Supply Voltage:
16.8 → 30 V dc, 19.2 → 28.8 V ac
Input Type:
Analogue
Termination:
Screw
Special Features:
2-Way Isolation
Maximum Operating Temperature:
+60°C
Minimum Operating Temperature:
-25°C
Signal Conditioner Type:
Analogue to Analogue
