American Wire Gauge:
22 AWG
Current Rating:
4 A
Conductor Resistance:
57 O/km
Oil Resistant:
Yes
Number of Cores:
5
Connector 2 Housing Gender:
Female
Outer Diameter:
4.8mm
Number of Strands:
42
Sheath Material:
PUR
Cable Shape:
Single Core
IP Rating:
IP65, IP66K, IP67
Core Strands:
42 x 0.1 mm
Operating Temperature Range:
-25 → +80 (Mobile) °C, -25 → +85 °C, -40 → +80 (Fixed) °C
Maximum Operating Temperature:
+80 (Fixed, +85 °C, Mobile) °C
Voltage Rating:
30 V ac/dc, 125 V ac/dc
Connector 1 Orientation:
Straight
Minimum Bend Radius:
24 (Fixed) mm, 48 (Moving) mm
Fire Behaviour:
Flame Retardant
Connector 1 Gender:
Male
Length:
1.5m
Connector 2 Orientation:
Right Angle
Connector 2 Gender:
Female
Connector 2 Number of Contacts:
5
Series:
A-Coded
Size of Strands:
0.1 mm
Connector 1 Number of Contacts:
5
Sheath Colour:
Black
Cross Sectional Area:
0.34 mm²
Minimum Operating Temperature:
-25 (Mobile) °C, -40 (Fixed) °C
Connector 2:
M12
Connector 1:
M12
Connector 1 Housing Gender:
Male
