This is T417 Series Industrial Automation Cable Assembly with a 3 Pole M12 Connector Female and a Wire Lead manufactured by TE Connectivity. The manufacturer part number is T4171110003-001. Features 22 awg - American Wire Gauge. The product has a current rating of 4 a. The conductor has ≤10 mω resistance. The product consists of 3 cores. The product complies with all safety standards, such as iec 61076-2-101, ul, ul 94 v-0. Moreover, this cable has a multicore shape. It is IP rated with ip67. Moreover, the product is unshielded . The product has -40 → +85 °c of operating temperature range. It has a maximum operating temperature of +85°c. Moreover, the product has a nominal 250 v ac/dc voltage rating. The connector 1 has a straight orientation. The product has a self-extinguishing fire behaviour. This connector 1 is a female. Its accurate length is 200mm. The sheath is constructed from durable and adorable pvc material. The product is available in panel mount configuration. The conductor is made from copper material. The product t417, is a highly preferred choice for users. On the other hand, the gender of connector 1's housing is female. There are 3 contacts on connector 1. The product is coded with a. The product has 0.34 mm² cross section area. Whereas, the minimum operating temperature of the product is -40°c. While the Connector 2 is unterminated. Connector 1 is m12. It has a robust pvc insulation material.
For more information please check the datasheets.
