American Wire Gauge:
24 AWG
Current Rating:
4 A
Conductor Resistance:
78.6 /km
Number of Cores:
2
Connector 2 Housing Gender:
Male
Outer Diameter:
7.8mm
Number of Strands:
19
Standards Met:
IEC 60332-1-2, UL 1581
Cable Shape:
Multicore
IP Rating:
IP65, IP67
Core Strands:
19 x 0.13 mm
Shielded/Unshielded:
Shielded
Operating Temperature Range:
-30 → +80 (Flexible) °C, -40 → +80 (Fixed) °C
Maximum Operating Temperature:
+80°C
Voltage Rating:
250 V
Connector 1 Orientation:
Right Angle
Minimum Bend Radius:
40 (Fixed) mm, 65 (Movable) mm
Connector 1 Gender:
Female
Length:
300mm
Characteristic Impedance:
150 Ω
Sheath Material:
PUR
Connector 2 Orientation:
Right Angle
Connector 2 Gender:
Male
Connector 2 Number of Contacts:
2
Conductor Material:
CuSn
Series:
SAC-2P-MRB/0.3-910/FRB SCO
Size of Strands:
0.13 mm
Connector 1 Number of Contacts:
2
Coding:
B
Sheath Colour:
Purple
Cross Sectional Area:
0.25 mm²
Minimum Operating Temperature:
-30 (Flexible) °C, -40 (Fixed) °C
Connector 2:
M12
Connector 1:
M12
Connector 1 Housing Gender:
Female
Insulation Material:
Foam PE
1st Connector Orientation:
B
2nd Connector Mounting Type:
Free Hanging (In-Line)
HTSUS:
8544.42.9090
1st Connector Shell Size - Insert:
M12
Cable Material:
Polyurethane (PUR)
Usage:
Industrial Environments
Shielding:
Shielded
1st Connector Number of Positions Loaded:
All
2nd Connector Type:
Plug, Right Angle
Assembly Configuration:
Standard
2nd Connector Number of Positions:
2
2nd Connector Number of Positions Loaded:
All
Package:
Bulk
Length:
1.08' (330.00mm)
Ingress Protection:
IP65/IP67 - Dust Tight, Water Resistant, Waterproof
standardLeadTime:
6 Weeks
1st Connector Type:
Receptacle, Right Angle
2nd Connector Shell Size - Insert:
M12
1st Connector Number of Positions:
2
1st Connector Gender:
Male Pins
Color:
Red
Series:
-
2nd Connector Orientation:
B
Cable Type:
Round
2nd Connector Gender:
Female Sockets
1st Connector Mounting Type:
Free Hanging (In-Line)
ECCN:
EAR99
