Repetitive Peak Forward Blocking Voltage:
1200V
Repetitive Peak Reverse Voltage:
1200V
Peak On-State Voltage:
1.3V
Dimensions:
92 x 50 x 49mm
Mounting Type:
Panel Mount
Surge Current Rating:
17kA
Rated Average On-State Current:
560A
Repetitive Peak Off-State Current:
40mA
Package Type:
Y1 CU
Minimum Operating Temperature:
-40 °C
Maximum Holding Current:
300mA
Maximum Gate Trigger Current:
300mA
Thyristor Type:
SCR Module
Maximum Operating Temperature:
+140 °C
Pin Count:
4
Maximum Gate Trigger Voltage:
2V
HTSUS:
8541.30.0080
RoHS Status:
ROHS3 Compliant
Voltage - Off State:
1.2 kV
Voltage - Gate Trigger (Vgt) (Max):
2 V
Operating Temperature:
-40°C ~ 140°C (TJ)
Package / Case:
Y1-CU
Current - Hold (Ih) (Max):
300 mA
REACH Status:
REACH Unaffected
Current - On State (It (RMS)) (Max):
880 A
Structure:
Single
Package:
Box
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - Gate Trigger (Igt) (Max):
300 mA
standardLeadTime:
20 Weeks
Current - Non Rep. Surge 50, 60Hz (Itsm):
17000A, 16000A
Mounting Type:
Chassis Mount
Current - On State (It (AV)) (Max):
560 A
Series:
-
Number of SCRs, Diodes:
1 SCR
Base Product Number:
MCO500
ECCN:
EAR99
