Actuator Shape:
Rectangular
DC Voltage Rating:
24V
Panel Cut Out Height:
36.83mm
Actuator Colour:
Black
Illuminated:
Yes
Mounting Type:
Panel Mount
IP Rating:
IP66, IP68
Contact Current Rating:
15 A
Minimum Operating Temperature:
-40°C
Operating Temperature Range:
-40 → +85°C
Panel Cut Out Size:
36.83 x 21.08mm
Contact Configuration:
DPST
Case Material:
Polyester
Panel Cut Out Width:
21.08mm
Contact Resistance:
10mΩ
Mechanical Life:
150000Cycles
Switch Operation:
On-(On)
Maximum Operating Temperature:
+85°C
Terminal Type:
Quick Connect
Contact Material:
Silver, Silver Alloy, Silver Tin Oxide
HTSUS:
8536.50.9065
RoHS Status:
ROHS3 Compliant
Electrical Life:
100,000 Cycles
Termination Style:
Quick Connect - 0.250" (6.3mm)
Voltage Rating - DC:
24 V
Operating Temperature:
-40°C ~ 85°C
Approval Agency:
CSA, UL, VDE
Panel Cutout Dimensions:
Rectangular - 36.83mm x 21.08mm
Mechanical Life:
100,000 Cycles
Color - Actuator/Cap:
-
REACH Status:
REACH Unaffected
Illumination Type, Color:
LED, Green/Green
Switch Function:
On-On
Actuator Marking:
Varies by Cap
Circuit:
DPDT
standardLeadTime:
8 Weeks
Current Rating (Amps):
15A (DC)
Ingress Protection:
IP66/IP68 - Dust Tight, Water Resistant, Waterproof
Features:
-
Mounting Type:
Panel Mount, Snap-In
Series:
Contura® V
Packaging:
Bulk
Actuator Type:
Actuator Arm, Cap Required - Illuminated
Illumination Voltage (Nominal):
24 VDC
Base Product Number:
VDB2UJJC
ECCN:
EAR99
