Actuator Shape:
Rectangular
DC Voltage Rating:
24V
Panel Cut Out Height:
44.04mm
Actuator Colour:
Black
Illuminated:
No
Mounting Type:
Panel Mount
IP Rating:
IP67, IP68
Contact Current Rating:
15 A
Minimum Operating Temperature:
-40°C
Operating Temperature Range:
-40 → +85°C
Panel Cut Out Size:
44.04 x 22.02mm
Contact Configuration:
Single Pole Single Throw (SPST)
Case Material:
Polyester
Panel Cut Out Width:
22.02mm
Contact Resistance:
10mΩ
Mechanical Life:
250000Cycles
Switch Operation:
On-On-Off
Maximum Operating Temperature:
+85°C
Terminal Type:
Quick Connect
Contact Material:
Gold, Silver Nickel, Silver Tin Oxide
HTSUS:
8536.50.9065
RoHS Status:
ROHS3 Compliant
Electrical Life:
100,000 Cycles
Termination Style:
Quick Connect - 0.250" (6.3mm)
Voltage Rating - DC:
24 V
Operating Temperature:
-40°C ~ 85°C
Approval Agency:
-
Panel Cutout Dimensions:
Rectangular - 44.04mm x 22.02mm
Mechanical Life:
100,000 Cycles
REACH Status:
REACH Unaffected
Illumination Type, Color:
-
Package:
Bulk
Switch Function:
On-On-Off, On-Off-Off
Actuator Marking:
No Marking
Circuit:
DPDT
Current Rating (Amps):
15A (DC)
Ingress Protection:
IP67 - Dust Tight, Waterproof
Features:
-
Mounting Type:
Panel Mount, Snap-In
Series:
L
Color - Actuator/Cap:
-
Actuator Type:
Actuator Arm, Cap Required
Illumination Voltage (Nominal):
-
Base Product Number:
L68B1S001
ECCN:
EAR99
