Actuator Shape:
Rectangular
Panel Cut Out Height:
13.97mm
Actuator Colour:
Black
Panel Cut Out Width:
28.58mm
Mounting Type:
Panel Mount
Legend Text:
On (symbol); Off (symbol)
Contact Current Rating:
10 A @ 125 V ac
Operating Temperature Range:
0 → +85°C
Legend Text Colour:
Red
Contact Configuration:
Single Pole Single Throw (SPST)
Case Material:
Nylon
Minimum Operating Temperature:
0°C
AC Voltage Rating:
125V
Mechanical Life:
100000Operations
Panel Cut Out Size:
13.97 x 28.58mm
Maximum Operating Temperature:
+85°C
Terminal Type:
Quick Connect
Switch Operation:
Latching
HTSUS:
8536.50.9065
RoHS Status:
ROHS3 Compliant
Electrical Life:
100,000 Cycles
Termination Style:
Quick Connect - 0.250" (6.3mm)
Operating Temperature:
0°C ~ 85°C
Approval Agency:
BEAB, CSA, DEMKO, FIMKO, NEMKO, SEMKO, SEV, TUV, UL, VDE
Panel Cutout Dimensions:
Rectangular - 28.58mm x 13.97mm
Mechanical Life:
-
Voltage Rating - AC:
125 V
REACH Status:
REACH Unaffected
Illumination Type, Color:
-
Package:
Bulk
Switch Function:
On-Off
Actuator Marking:
O -
Circuit:
SPST
standardLeadTime:
12 Weeks
Current Rating (Amps):
16A (AC)
Ingress Protection:
-
Features:
-
Mounting Type:
Panel Mount, Snap-In
Series:
R
Color - Actuator/Cap:
Black, Red
Actuator Type:
Concave (Curved)
Illumination Voltage (Nominal):
-
Base Product Number:
RA911
ECCN:
EAR99
