Analog Devices ADG918BCPZ-REEL7, RF Switch 4GHz Single SPDT 36dB Isolation CMOS/LVTTL 1.65 → 2.75 V 8-Pin LFCSP

ADG918BCPZ-REEL7 Analog Devices , RF Switch 4GHz Single SPDT 36dB Isolation CMOS/LVTTL 1.65 → 2.75 V 8-Pin LFCSP
ADG918BCPZ-REEL7
ADG918BCPZ-REEL7
ET14102350
ET14102350
Analog Devices

Product Information

Minimum Isolation:
36dB
Dimensions:
3.25 x 3.25 x 0.85mm
Mounting Type:
Surface Mount
Minimum Frequency:
0MHz
Maximum Insertion Loss:
1.25dB
Maximum Operating Temperature:
+85 °C
Number of Switches:
1
Switch Configuration:
Single SPDT
Height:
0.85mm
Width:
3.25mm
Length:
3.25mm
Package Type:
LFCSP
Maximum Frequency:
4GHz
Minimum Operating Temperature:
-40 °C
Maximum Operating Supply Voltage:
2.75 V
Switching Speed:
10ns
Minimum Operating Supply Voltage:
1.65 V
Technology:
CMOS/LVTTL
Pin Count:
8
RoHs Compliant
Checking for live stock

This is RF Switch 4GHz Single SPDT 36dB Isolation CMOS/LVTTL 1.65 → 2.75 V 8-Pin LFCSP manufactured by Analog Devices. The manufacturer part number is ADG918BCPZ-REEL7. 36db is the minimum isolation offered . The given dimensions of the product include 3.25 x 3.25 x 0.85mm. The product is available in surface mount configuration. It has a minimum 0mhz frequency . It has a maximum 1.25db insertion loss . It has a maximum operating temperature of +85 °c. The number of switches include 1 . It is created with a/an single spdt switch configuration . In addition, the height is 0.85mm. Furthermore, the product is 3.25mm wide. Its accurate length is 3.25mm. The package is a sort of lfcsp. It features 4ghz of maximum frequency. Whereas, the minimum operating temperature of the product is -40 °c. It has 2.75 v maximum operating supply voltage. It has about 10ns switching speed . While its minimum operating supply voltage is 1.65 v. This product use cmos/lvttl technology. It contains 8 pins.

pdf icon
ADG918/ADG919, Wideband 4 GHz, 43 dB Isolation at 1 GHz, CMOS 1.65 V to 2.75 V, 2:1 Mux/SPDT(Technical Reference)
pdf icon
ESD Control Selection Guide V1(Technical Reference)

Reviews

  • Be the first to review.

FAQs

Yes. You can also search ADG918BCPZ-REEL7 on website for other similar products.
We accept all major payment methods for all products including ET14102350. Please check your shopping cart at the time of order.
You can order Analog Devices brand products with ADG918BCPZ-REEL7 directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in RF Switch Circuits category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Analog Devices ADG918BCPZ-REEL7, RF Switch 4GHz Single SPDT 36dB Isolation CMOS/LVTTL 1.65 → 2.75 V 8-Pin LFCSP. You can also check on our website or by contacting our customer support team for further order details on Analog Devices ADG918BCPZ-REEL7, RF Switch 4GHz Single SPDT 36dB Isolation CMOS/LVTTL 1.65 → 2.75 V 8-Pin LFCSP.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET14102350 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Analog Devices" products on our website by using Enrgtech's Unique Manufacturing Part Number ET14102350.
Yes. We ship ADG918BCPZ-REEL7 Internationally to many countries around the world.
