Frequency Range:
1.202GHz ~ 1.207GHz, 1.246GHz ~ 1.248GHz, 1.601GHz ~ 1.602GHz
HTSUS:
8529.10.4040
RoHS Status:
ROHS3 Compliant
Frequency Group:
UHF (1GHz ~ 2GHz)
Height (Max):
0.642" (16.30mm)
Applications:
Beidou, Galileo, GLONASS, GNSS, GPS
Gain:
25dBi, 27.4dBi, 23.4dBi, 28.4dBi, 32.4dBi, 32.4dBi
Number of Bands:
6
Package:
Bag
Moisture Sensitivity Level (MSL):
Not Applicable
RF Family/Standard:
Navigation
Frequency (Center/Band):
1.2045GHz, 1.228GHz, 1.247GHz, 1.561GHz, 1.575GHz, 1.6015GHz
Termination:
SMA Male
standardLeadTime:
12 Weeks
Ingress Protection:
-
Features:
Cable - 1m, LNA
Mounting Type:
Magnetic
Antenna Type:
Module
Series:
GNRM
VSWR:
1.1, 1.2, 1.5, 1.6, 1.7
Return Loss:
-11.6dB, -13.3dB, -14.4dB, -19.2dB, -25dB
ECCN:
7A994
